PSG Stove Max Caddy

Type of fuel	Wood
Maximum input capacity	180,000 BTU (53 kW)
Maximum output capacity	137,970 BTU (41 kW)
Average output capacity	89,680 BTU (27 kW)
Blower	G-10 blower with 1/2 hp motor - theoretical 1780 CFM (max 0.20'' WC) - 4 speeds
Loading capacity	Up to 90 lbs (41kg)
Efficiency	85% (LHV) 77 % (HHV)
Color	Green
Exterior dimensions	(Including the blower assembly): 30"W x 62"D x 50"H
Flue spigot diameter	6"
Recommended exhaust pipe diameter	6" if installed as wood or wood-electric combination 7" if installed as wood-oil combination
Type of chimney	2100°F (1150°C)
Firebox dimensions	20 3/8"W x 26 ¼"D x 14 ½" H
Maximum log length	25"
Door opening dimensions	15 11/16"W x 10"H
Type of door	Glass with cast iron frame
Hot air plenum dimensions	25 7/16''W x 32 1/8''D
Cold air plenum dimensions	20''W x 18''D
Ash drawer dimensions	11 15/16''W x 19 5/8''D x 2 5/8''H
Number of filters	1
Filters dimensions	16" x 20"
Minimum clearances (Front)	48"
Minimum clearances (Back)	24"
Minimum clearances (Sides)	6'' (wood only) and 24'' on the option side
Minimum clearances (Ducts)	6" for the first 6' with a screen at ¾" and 1" thereafter
Weight	650 lbs (295 Kg)
Warranty	Limited lifetime warranty
Test standard - safety	Can CSA B366.1, UL 391, CAN/CSA C22.2 no 236, UL 1995, CSA B140.4, UL 727
Test standard - emissions	CSAB415.1-10
